Technical Specifications


  • Automatically getting Schedule
  • Auto trip start/stop
  • Real time route information on Google Map with next stop
  • distance, next ETA, odometer, speed, alerts etc.
  • Display of schedule ID, driver & conductor etc.
  • Automatic stop announcement and concurrently displaying
  • stop information on the LED boards
  • Support location based advertisement
  • Alert generation such as ignition, internal battery status, over speed, harsh acceleration / breaking, mains status, emergency etc.
  • Support for pushing messages from control centre to display on the boards as well as announcement
  • Two voice calls only for pre-configured phone numbers
  • Automatic reverse video streaming when reverse gear applied
  • Liver video streaming up to 4 cameras
  • Support for snaps shots
  • Vehicle Heath Diagnostics
  • Automatically getting route files
  • Support more than 1000 routes with 100 stops per route
  • Up to 10 hours of internal battery
  • Regional language Support
  • >150K waypoint storage in case of loss communication
  • Supports DTC and PID
  • Supports display boards DTC and PID information
  • Supports display board configuration and diagnostics
  • Impact/accident alerts
  • Public announcement
  • Support for RFID and Passenger counting

Technical Specification

  • CPU: A83T ARM Cortex-A7 octa-core,512 KB L1 cache 1 MB L2 cache
  • GPU: PowerVR SGX544MP1· Comply with OpenGL ES 2.0, OpenCL 1.x, DX 9.3
  • RAM: 2GB LPDDR3 with 733MHz(shared with GPU)
  • WiFi: WiFi 802.11 b/g/n
  • Bluetooth: BT4.0
  • Storage Memory: 8GB eMMC
  • SDCARD: up to 64GB
  • Video: Multi-format FHD video decoding, including Mpeg1/2, Mpeg4, H.263, H.264, etc H.264 high profile
  • 1080p@60fps or 720p@120fps encoding, HEVC/H.265 decoder 1080P@30fps with software
  • 7” Capacitive touch screen
  • 4 Digital Inputs, 4 Digital Outputs and 4 Analogue Inputs
  • RS-485 Interface
  • RS-232 Interface
  • 4 - 10/100 Ethernet Interface for IP Camera
  • USB 2.0
  • Emergency , break down, fire etc. keys
  • Built-in 80W audio amplifier
  • Two way voice communication
  • 3G/4G with GPS/GLONASS
  • 3D Accelerometer & Gyroscope
  • Ignition detection Input
  • Optional HDMI interface
  • Internal Battery charging etc.


  • Intelligent Transport System
  • Vehicle Tracking System
  • Bus Passenger Information System
